21
Specifications
Except where otherwise stated, this specification applies at an ambient temperature of 20 ºC
General
Ranges: 10 m 25 m 100 m 250 m 1000 m 2500 m 5000 m
30 ft 75 ft 300 ft 750 ft 3000 ft 7500 ft 15000 ft
Accuracy: ±1% of range ± pixel at 0.67 VF
[Note- The measurement accuracy is for the indicated cursor position only and is conditional on the
velocity factor being correct.]
Resolution: 1% of range
Output pulse: 5 volts nominal peak to peak into open circuit. Pulse widths determined by range and cable
Gain: Set for each range with three user selectable steps (in Manual operating mode)
Velocity Factor: Variable from 0.2 to 0.99 in steps of 0.01
Power Down: Automatic after 5 minutes with no key press
Backlight: Stays on for 1 minute with no key press when activated
Batteries: Five LR6 (AA) type batteries, Manganese alkali or nickel metal-hydride cells
Battery Life: 14 hours typical.
Safety
When using the Fused Test Lead Set this instrument complies with EN 61010-1 for connection to live systems with less than 300V between
the terminals and 150V CATIV to earth. When using the Miniature clip Test Lead Set, Bed of Nails Test Lead Set or BNC Adapter the system
is rated for safety low voltage systems only.
EMC
Complies with Electromagnetic Compatibility Specifications (Light industrial) BS EN 61326-1, with a minimum performance of ‘B’ for all
immunity tests
