Write command 7
1. The main module defines the frame with the MCbus communication buffer. See tables 3-6 and 3-7 for
the definition of D components and write command 7.
Table 3-9 Settings represent communication special meaning D element
Table 3-10 Definition of D element for write command 7
CH1 heat side proportional
band
CH1 heat side derivative
time
CH2 heat side proportional
band
CH2 heat side derivative
time
CH3 heat side proportional
band
CH3 heat side derivative
time
CH4 heat side proportional
band
CH4 heat side derivative
time
CH1 heat side integral time
CH2 heat side integral time
CH3 heat side integral time
CH4 heat side integral time
2. MTC thermostat return the frame with the MCbus communication buffer. Take MTC#1 region as an
example: when D7532 and D7563 change to 7, the write is successful and up to 30 D elements can be
written at a time. The return frame definition is shown in the following table.
Table 3-11 MTC thermostat communicate the return frame of the buffer of write command 7
CH1 heat side proportional
MTC module station
number to be read
To Next Page
