meibes MeiFlow MFR3 User Manual

°C
T1
60.0
65.5
°
Basic screen
Type of operation
Actual temperature
Target temperature
- Heating
- Cooling
- Valve rotation direction
counter clockwise
- Valve rotation direction
clockwise
- Return flow temperature
- Flow temperature
- Transmission deactivated
- Target temperature
- Error
Type of operation
Actual and target temperature
Hydraulic diagram
Displayed symbols:
60
T1=65
°C
°C
°C
T1
60.0
65.5
°
Valve direction setting - shortcut
5s
User instructions
1x
User instructions
°C
T1
60.0
65.5
°
°C
T1
60.0
65.5
°
Target temperature setting
1s and
50 70
60.0
°
5s
Manual operation
Basic screen
T1
65.5
°
1
2
Error
Basic screen
Basic screen
T1
Error
60
°C
T1=Err
Heating / cooling selection
Assembly and electr. connection
230V AC, 50 Hz
fixed connection
via Schuko plug
Technical data
Dimensions
When the clutch is activated, the control of the mixing valve switches off.
Manual movement of the
mixing valve is activated by
pressing the clutch button.
The desired position of the
mixing valve is set by turning
the rotary knob. With renewed
pressure on the clutch button,
manual movement is
deactivated.
and confirmed with button .
Replacement of the power cord
If the power cord is damaged, it can be replaced. The
cable is equipped with the mains plug and connector.
To replace the cable, the cable protection cover must
first be removed.
The replacement of the power cord is only
possible with the
original power cord.
Fatal risk of electric shock!
Before starting the installation, always make sure that
you are completely disconnected from the mains and
secure against being switched on again!
Settings are made with buttons and
and confirmed with button .
Settings are made with buttons and
and confirmed with button
i
i
!
T1:
Temp. sensor type: Pt1000,
firmly connected,
Cable length: 0.5 m
Sensor diameter: 5 mm
80,3
95
61
34
86,5
Torque:
Rotation angle:
Rotation speed
Type of operation:
Supply voltage:
Max. power consumption:
Temperature range:
Protection class:
Protection class:
Dimensions (W × L × H):
Weight:
Colour / material:
Battery:
Clock accuracy:
6 Nm
90 <°
2 min / 90 <°
3-point, PID
230V AC, 50 Hz
3.5 VA
0 ÷ 50 °C
IP42 according to EN 60529
I according to EN 60730-1
86.5 x 95 x 80.3 mm
900 g
Dark gray / PC
CR1025 (Li-Mn) 3V
+/- 1s (24h) at 20 °C
71
Basic screen
Basic screen
Settings are made with buttons and
Basic screen
