Lubrication and Attachment of An ‘Ahead Set Stem To
The Fork Diagram:
42
The brake pads should be lined up on the rim when the
brake levers are pulled. They should not make contact with
the tire or be positioned too far towards the center of the
wheel. Loosen the 5mm adjustor on the outside of the
brakes to reposition the pads.
Adjust the response of the brakes by loosening the locking
wheel and then loosening or tightening the barrel adjustor
(counterclockwise increases cable tension, clockwise re-
duces cable tension). When the response is what you want,
tighten the locking wheel back in place. If greater adjust-
ment is needed, loosen the adjustor that holds the brake
cable on one side of the brakes. Move the cable in or out
and tighten the screw again.
19
