Rear Wheel Replacement
1. Wheel replacement virtually follows the reverse process
to rear wheel removal
2. Hold the rear derailleur spring fully back and feed the
top part of the smallest hub cog into the top part of the
chain. Fit the wheel into the frame.
3. Ensure the wheel is centered correctly in the frame and
then fi rmly secure both axles nuts. To test if the wheel is
centered, inspect the distance between the front of the
wheel and the frame chainstay tubes on either side.
4. Reset the brake quick release and check the brake pad
clearance. If required, adjust the brake cable/pad clear-
ance.
Caution:
Take care to correctly refi t a rear wheel. Failure
to do so may be dangerous.
Rear Wheel Removal
1. Open the brake quick release. Undo the brake cable
anchor bolt if greater clearance is required.
2. Move the chain onto the smallest rear cog.
3. When the wheel is fi tted with standard axle nuts, loosen
them with a 15mm wrench.
4. Hold the derailleur unit and allow the wheel to slide for-
ward out of the frame.
5. Rest the bike upside down on the handlebars and sad-
dle. After wheel is removed, do not rest bike on rear de-
railleur, as it may be damaged or misaligned as a result.
34
Frequency Component Lubricate How to Lubricate
Weekly Chain chain lube or
light oil
brush on or squirt
Derailleur
wheels
lube or light oil brush on or squirt
Derailleurs oil oil can
Brake callipers oil drops from oil can
Brake levers oil 2 drops from oil
can
Monthly Shift levers lithium based
grease
disassemble
Brake cable
ends
oil 1 drop from oil
can
Bi-Annual Hubs lithium based
grease
disassemble
Bottom bracket lithium based
grease
disassemble
Pedals lithium based
grease
disassemble
Brake cables lithium based
grease
disassemble
Derailleur
cables
lithium based
grease
disassemble
Yearly Wheels bear-
ings
lithium based
grease
disassemble
Headset lithium based
grease
disassemble
Seat pillar lithium based
grease
disassemble
Schedule 1 - Lubrication
Note: Increase the regularity of maintenance the more you
ride and use in wet or dusty conditions.
Take care not to over lubricate – excess lubricant should be
removed to prohibit dirt build up.
27
