Memorex MiHTS3202 - 32" Front Sound Speaker System Service Manual

LIST OF SPARE PART
MATERIEL NO. MATERIEL DESCRIPTION MATERIEL NO. MATERIEL DESCRIPTION
31-0701-0000009LF
Power switch(Rohs),KCD1-B3 240AVC, CQC(03002008030)
,UL(E203463)VDE(400012587)
31-0312-9014000LF SMD Audion(Rohs),C9014
31-0901-2116121LF
TE-2116i Transformer(Rohs),EI76*42*102
AC120V/60Hz,200mm,AC14V*2 AC13V*2 AC5.8V AC9V
31-0413-4002000LF SMD Commutate diode(Rohs),IN4002
31-1211-1200011LF 110120 04402Q speaker(Rohs),4Ω RMS 30W MAX 50W 31-0414-5010510LF SMD Zener Diode(Rohs),1/2W 5.1V
31-1231-0130002LF 310013 00101Q speaker(Rohs),4Ω RMS 5W MAX 10W 31-0414-5012400LF SMD Zener Diode(Rohs),1/2W 24V
31-1241-0660035LF 410066 03825Q speaker(Rohs),2.5" 8Ω RMS 20W 31-0502-1341S20LF
SMD IC(Rohs),MF1341S2160 (ipod Authentication ,
Coprocessor V2.0B C1ass2 )
31-2111-2212250LF Flexible flat wire (Rohs)KB-1.0-12P*250-4/8,12PIN 250MM 31-0502-24C0200LF SMD IC(Rohs),24C02
31-4001-1252020LF
Fuse(Rohs),T2L 250V Ф5*20)UL(249609) ,
CCC(2003010207097836)VDE(40009610)
31-0502-4052000LF SMD IC(Rohs),4052
31-0501-7265000LF IC TDA7265(Rohs),TO-220-11 31-0502-4558000LF SMD IC(Rohs),4558
31-0501-7805000LF IC(Rohs),CW7805 TO-220-3 31-0502-8206000LF SMD IC(Rohs) AP8206Q,SRS
31-0501-78L0500LF IC WL78L05(Rohs),TO-92 31-0507-2116001LF TE-2116i CPU(Rohs),SMD,QFP44
31-0601-4780500LF Differentiate color inductance(Rohs),4.7uH 31-0401-4148000LF SWITCH DIODE(ROHS),IN4148
31-1802-2110590LF Metal oscillator(Rohs),11.0592MHZ 31-0403-5010510LF Zener diode(Rohs),1/2W 5.1V
31-3301-0000000LF Commutate bridge(Rohs),6A\600V 31-0406-0102014LF LBD(Rohs),Φ3*27mm 3R4PD-302
31-3802-2290000LF MAGNETISM BEAD(ROHS),0.22UH(Ф3.5*5) 31-0502-6311000LF SMD IC(Rohs),PT6311
31-4002-1251023LF Microminiature Fuse(Rohs)T1A/250V,Ф2.5*5 31-1101-0000001LF VFD(Rohs),FD25-1007(25*135mm)
31-4002-1255022LF Microminiature FuseT5A 250V(Rohs),Ф3*10 3C、VDE、UL 31-3802-2290000LF MAGNETISM BEAD(ROHS),0.22UH(Ф3.5*5)
31-0703-0606112LF Touch switch(Rohs),6*6*11 160±50gf(IT-1102-G2-01) 31-4301-1030000LF REMOTE RECEIVE IC(ROHS),BRM-1030 18mm
31-1406-0101306LF IPOD 30P jack(Rohs),514SO117 31-3001-0202002LF S-video jack(clubfoot)(Rohs),AV1-8 4-12SD2
21-1801-3916006LF HT-3916Remote control subassembly(MEMOREX),(Rohs) 31-3001-0204002LF Core jack(Rohs),AV4-8 4-7
