Memorex MLT3252 User Manual

- 15 -
Connect an external device that utilizes Audio/Video jacks as follows:
1
Make sure the power is off on the TV and external unit.
2
Connect the red and white plugs of an audio cable (not included) from the Audio Out
jacks on the external unit to the red and white Component AV1 Audio In jacks on the
rear of the TV.
3
Connect the yellow (video) plug from the Video Out jack on the external unit to the
yellow Video In jack on the rear of the TV.
4
Turn on the TV and external unit.
5
Press the SOURCE button and then select AV using the Navigation q/p buttons.
Conrm by pressing the OK button.
DVD
HD Cable Box
etc.
(Not
Included)
Out Jacks on External Unit
VIDEO
O
L R
O
NOTE: It is very important to insert the correct color plug into the same color jack.
INSTALLATION
Composite Cable Connection
