Memphis Audio built a 50 year legacy in the audio industry engineering the highest quality products to produce
the best possible listening experience for our fans and loyal supporters. To fully appreciate our products we
recommend taking the time to read and follow the instructions in this manual. As always, we recommend all
installations and service be performed by an authorized Memphis Audio dealer.
Built in Bluetooth receiver
Passive radiator for enhanced mid bass
Resistant to water and elements
Dual adjustable clamp fits bars 1”-2.5” tubes
Self powered Plug & Play for quick installation
AUX input
2-Channel output
• 10 Speaker system- 8 x 3” speakers and 2 x 1“ tweeters
• Total Power: 300 Watts
• Dimensions 35.78” x 3.5” x 3.9“
• Clamp Fit: 1.25”-2.75“ Tube Mounts
For optimal performance, Memphis recommends using only Memphis Connection accessories. Outfitting
your system with properly sized Memphis Connection wire and accessories will dramatically boost your
listening experience and increase the durability of your Memphis Audio products.
MXASB35
CONTROLS
INSTALLATION INSTRUCTIONS
The Memphis MXASB35 Sound bar is designed to make it easy to bring Memphis sound to virtually any vehicle. The
easy to install, all in one unit is transforms your Bluetooth enabled device into the controls for your entire Audio
experience. The multiple mounting options allow the MXASB35 to fit on nearly any UTV, Boat, golf cart or anything
with a bar to mount it on. The MXASB35 was designed to be resistant to the outdoor elements, so get ready to
enjoy that Memphis Sound wherever you are!
Bluetooth pairing:
Hold the power button to turn the unit on. The indicator light will begin flashing blue. Go to your device and search
for “Memphis SB35” and click connect. The blue light will stay solid blue when connected.
Bluetooth Operation:
Power Button: Hold for power on/off. Quick press to select between Bluetooth and Aux in modes
Play Pause: Pauses and Plays the music. (Mutes music when in Aux-in mode)
Track Forward/Back: Skips tracks forward and back
V+/V-: Controls the volume of the internal amplifier
Status Light: Flashes Blue when in Bluetooth Discovery mode. Solid blue when connected to a device. Solid green
when in AUX in mode.
Wiring:
Red – 12V constant, should be connected directly to the vehicle positive battery terminal
Black – 12V negative, should be connected directly the vehicle chassis where the paint is removed or
directly to the negative battery terminal
Blue – 12V switched, This should be connected to the vehicle ignition or external switch. When this wire
is connected to +12V the soundbar will turn on.
Optional Wiring:
The green female 3.5mm jack is to be used for and optional Auxiliary input. You can use this jack to connect any
audio device via 3.5mm jack.
The white female 3.5mm jack is a 2.5v low level audio out designed to drive external amplifiers. This allows the
MXASB35 to be used as the main source while adding more audio components to your system.
SPECIFICATIONS
FEATURES
READY TO TURN IT UP? READ THIS FIRST!
