MENU Stick System Series - 3 X3 Stick System Assembly

40
3X3
1954 x 580 mm
734 x 580 mm
1954 x 957 mm
734 x 957 mm
734 x 1711 mm
1954 x 1711 mm
734 x 1334 mm
1954 x 1334 mm
Date: 130927
3x3
A
B
Pole 590 x18
Pole 357 x28
C
Male 52 x26
D
Female 52 x18
E
Pole 117 x8
F
Bracket x24
G
Shelf x9
