1.Connect the footrest and seat plugs, then connect air tube
corresponding color.
2.Make surely the backrest for ward about 30 degree, attach the arc
of the pothook。
3.Connect the backrest and square pipe which under the seat with bolt
to fix. And connect the air tube and line.
4.Inser t the armrest to the seat groove as shown, fix them by M6*30
screw. And connect air tube corresponding color.
F
I
I
E
J
H
Assembly instruction Assembly instruction
7.Set up the controller shell by D screw,
then insert the controller.
8.Add the controller to control box. 9.Attach the power line to the control box.
5.Zip up the pillow on the backrest.
6.FIX the controller stand on the armrest by M5*10 screw.
G
A
B
C
D
13 14
