No. Description Qty No. Description Qty
1 Monitor 1 41 Cross Pan Screw ST3*10 5
2 Mid wire 1 42 Hexagon Nut M6 3
3 Upright Tube 1 43 Hexagon Bolt M6*60 1
4 Tension control 1 44 Hexagon Nut 2
5 Cross Pan Screw M5*50 1 45 Washer 1
6 Curved Washer D5 1 46 Tow-groove Nut 1
7 Curved Washer φ8.5*φ20*2 8 47 Ball frame 2
8 Spring Washer D8 10 48 Ball bowl 2
9 Inner Hexagon Pan Screw M8*20 4 49 Tri-groove Nut 1
10 Mid handlebar 1 50 Washer 1
11 Handlebar foam 2 51 Belt disk 1
12 Seat cushion 1 52 Cross Drown Screw ST4.2*20 2
13 Seat tube 1 53 Belt 1
14 Flat washer φ8 3 54 Flat Washer φ10.5*φ20*2 1
15 Nylon nut M8 3 55 Nylon Nut M10 1
16L L pedal 1 56 Idler sleeve 1
16R R Pedal 1 57 Idler 1
17 Rear bottom tube 1 58 External Hexagon Bolt M10*45 1
18 Rear Feet cap 2 59 Hexagon Round-head Screw M6*30 1
19 Square Bolt M8*73 4 60 Cross Pan Screw ST4.2*20 7
20 Domed Nut M8 4 61 Cross Pan Screw ST4.2*16 5
21 Hole End Cap 2 62 Sensor 1
22 Front bottom tube 1 63 Union crank 1
23 Feet cap 2 64L L cover 1
24 Main frame 1 64R R cover 1
25 Tension control down wire 1 65 Hole cap 2
26 Flywheel 1 66 Knob 1
27 Flywheel axis 1 67 Seat sleeve 1
28 Bearing support 2 68 Round Inner Tube cap 2
29 Bearing 6001RS 2 69 Inner Hexagon Pan Screw M8*30 2
30 Bearing board 2 70 Handlebar Cover 1
31 Hexagon Bolt M6*9 6 71 Screw M5*10 2
32 Flat Washer φ6.5*φ16*1.5 4 72 Pulse 2
33 Hexagon Bolt M6*15 4 73 Flat Washer φ6*φ12*1 2
34 Magnetic board 1 74 Pole 1
35 Magnetic board axis 1 75 Adjustable Horizontal Tube 1
36 Spring Washer D6 2 76 Square Inner End Cap 2
37 Snap ring D12 2 77 Open-groove Seat sleeve 1
38 Magnetic Grip 1 78 Seat sleeve 1
39 Black Magnetic 4 79 Flat Washer φ8.5*φ20*1.5 1
40 Tension spring 1
