360° camera
General notes
The 360° camera is a system consisting of four
cameras.
The system processes images from the follow-
ing cameras:
R
Rear view camera
R
Front camera
R
Two cameras in the exterior rear view mirrors
The cameras capture the immediate surround-
ings of the vehicle. The system supports you,
e.g. when parking or if vision is restricted at an
exit.
You can show pictures from the 360° camera in
full-screen mode or in seven different split-
screen views on the multimedia system display.
A split-screen view also includes a top view of
the vehicle. This view is calculated from the data
supplied by the installed cameras (virtual cam-
era).
The six split-screen views are:
R
top view and picture from the rear view cam-
era (130° viewing angle)
R
top view and image from the front camera
(130° viewing angle without displaying the
maximum steering wheel angle)
R
top view and enlarged rear view
R
top view and enlarged front view
R
top view and rear-view images from the exte-
rior mirror cameras (rear wheel view)
R
top view and forward-view images from the
exterior mirror cameras (front wheel view)
When the function is active and you shift the
transmission from D or R to N, the dynamic
guidelines are hidden.
When you change between transmission posi-
tions D and R, you see the previously selected
front or rear view.
Distances measured by PARKTRONIC will also
be optically displayed:
R
in split screen view as red or yellow brackets
around the vehicle icon in the top view, or
R
at the bottom right as red or yellow brackets
around the vehicle symbol in full-screen mode
The line thickness and color of the brackets
show how far the vehicle is from an object.
R
yellow brackets with thin lines: PARKTRONIC
is active
R
yellow brackets with normal lines: an object is
present in close range of the vehicle
R
red line: an object is present in the immediate
close range of the vehicle
i
The camera in the rear area is protected
from raindrops and dust by means of a flap.
When the camera is activated, this flap opens.
The flap closes again when:
R
you have finished the maneuvering process
R
you switch off the engine
R
you open the cargo compartment
Observe the notes on cleaning (
Y page 365).
For technical reasons, the flap may remain
open briefly after the camera has been deac-
tivated.
Important safety notes
The 360°camera is only an aid and may show a
distorted view of obstacles, show them incor-
rectly or not at all. The 360°camera is not a
substitute for attentive driving.
You are always responsible for safe maneuver-
ing and parking. When maneuvering or parking,
make sure that there are no persons, animals or
objects in the area in which you are maneuver-
ing.
You are always responsible for safety, and must
always pay attention to your surroundings when
parking and maneuvering. This applies to the
areas behind, in front of and beside the vehicle.
You could otherwise endanger yourself and oth-
ers.
The 360° camera will not function or will func-
tion in a limited manner:
R
if the doors are open
R
if the exterior mirrors are folded in
R
if the tailgate is open
R
in heavy rain, snow or fog
R
at night or in very dark places
R
if the cameras are exposed to very bright light
R
if the area is lit by fluorescent bulbs or LED
lighting (the display may flicker)
R
if there is a sudden change in temperature,
e.g. when driving into a heated garage in win-
ter
Driving systems
221
