MerCruiser 350 MAG MPI Owner's Manual

Section 5 - Maintenance
Page 72 90-864197070 JUNE 2007
Lubrication
Throttle Cable
1. Lubricate the pivot points and the guide contact surfaces.
a
b
a
5577
a - Pivot points b - Guide contact surfaces
Tube Ref. No. Description Where Used Part No.
Synthetic Blend MerCruiser Engine
Oil SAE25W‑40
Throttle cable pivot points &
guide contact surfaces
92‑883725K01
Transmission Linkage
IMPORTANT: The poppet ball must be centered in the detent hole for each F‑N‑R position.
1. Lubricate the detent ball and the holes in the shift lever.
a
5934
In‑Line Transmission
Tube Ref. No. Description Where Used Part No.
Synthetic Blend MerCruiser Engine
Oil SAE25W‑40
Detent ball and shift lever
holes
92‑883725K01

MerCruiser 350 MAG MPI Specifications

General

Engine Type	V8
Horsepower	300 HP
Ignition System	Electronic ignition
Alternator	65 amp
Compression Ratio	9.4:1
Displacement	5.7L (350 cu in)
Fuel System	Multi-Point Injection (MPI)
Bore x Stroke	4.00" x 3.48" (101.6mm x 88.39mm)
