Mercury Security MR51e User Manual

Mercury Security © 2015 MR51e DOC 10107-0035 REV 1.06 Page 8
FIELD WIRING
MR51e WITH INCLUDED
MOUNTING PLATE
TO ETHERNET
NETWORK
OPTIONAL 3-GANG
JUNCTION BOX
OPTIONAL BLANK
COVER W/SCREWS
OPTIONAL MAGNETIC
TAMPER SWITCH
11. Additional Mounting Information:
Sources for the optional items shown below:
 3-gang stainless steel blank cover. Available from:
Leviton part number 84033-40
Graybar part number 88158404
 Magnetic switch set: G.R.I. part number: 505
Side View:
Mounting Plate Dimensions:
3.85 [97.8]
2.35 [59.7]
5.50 [139.7]
3.63 [92.1]
3.30 [83.8]
3.63 [92.1]
Ø0.16 [Ø4.0]
MR50 MGT HOLES
4PL
Ø0.16 [Ø4.0]
3-GANG MGT HOLES
4PL
