Propeller Shaft

Ref. No. Qty. Description

Torque

Nm lb‑in. lb‑ft

1 1 Ball bearing

2 1 Forward gear

3 1 Push rod

4 1 Retainer spring

5 1 Clutch pin

6 1 Clutch

7 1 Spring

8 1 Propeller shaft

9 1 Thrust washer

10 1 Reverse gear

11 1 O‑ring

12 1 Ball bearing

13 1 Bearing carrier

14 1 Needle bearing

15 1 Oil seal

16 2 Screw 9.0 79.6 –

17 1 Propeller

18 1 Propeller hardware kit

19 1 Front thrust hub

20 1 Washer

21 1 Propeller nut 12.0 106.2 –

22 1 Cotter pin

Gear Housing (2.15:1)
