Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
106 40A** Anti-lock Brake System (ABS)
107 — Not used
108 — Not used
109 – Not used
110 – Not used
111 – Not used
112 50A** Ignition switch
113 50A** Feeds IP fuses 3, 5, 21, 23, 25, 27
114 30A** VAP Steering, Air suspension compressor,
Instrument cluster
115 50A** Ignition switch
116 30A** Wipers
117 – Not used
118 20A** ABS
201 1/2 ISO Horn relay
202 1/2 ISO PCM relay
203 1/2 ISO Fuel pump relay
204 1/2 ISO A/C clutch relay
205 1/2 ISO Traction control switch relay
206 — Not used
207 1/2 ISO Fog lamp relay (Marauder only)
208 1/2 ISO Moonroof relay
209 — Not used
301 Full ISO Blower motor relay
302 Full ISO Starter solenoid relay
303 Full ISO Air suspension relay
304 Full ISO Heated backlight relay
401 — Not used
501 Diode PCM diode
502 — Not used
503 — Not used
Roadside Emergencies
150
To Next Page
