Trip odometer: Registers the miles (kilometers) of individual journeys.
• Standard instrument cluster
Press and release the
SELECT/RESET button to toggle
between odometer and trip
odometer display.
• Optional instrument cluster
Press and release the TRIP/RESET
button to toggle between odometer
and trip odometer display.
Tachometer: Indicates the engine
speed in revolutions per minute.
Driving with your tachometer
pointer continuously at the top of
the scale may damage the engine.
Battery voltage gauge: Indicates
the battery voltage when the
ignition is in the ON position. If the
pointer moves and stays outside the
normal operating range (as
indicated by arrows), have the
vehicle’s electrical system checked
as soon as possible.
TRIP
2005 Mountaineer (mnt)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
