Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
37 — Not used
38 — Not used
39 — Not used
40 — Not used
41 — Not used
42 15A* PCM non-emission related
43 15A* Coil on plug
44 15A* PCM emission related
45 5A* PETA Pump feedback (PZEV engine
only)
46 15A* Injectors
47 1/2 ISO Relay Fog lamps
48 — Not used
49 — Not used
50 1/2 ISO Relay Wiper Park
51 1/2 ISO Relay A/C Clutch
52 — Not used
53 1/2 ISO Relay Wiper RUN
54 1/2 ISO Relay Transmission (I4 engine only)
55 Full ISO Relay Fuel pump
56 Full ISO Relay Blower motor
57 Full ISO Relay PCM
58 High Current
Relay
PETA Pump (PZEV engine only)
59 — Not used
60 Diode Fuel pump
61 Diode Not used
62 Circuit
Breaker
Spare
*Mini fuses **A1 fuses ***A3 fuses
2007 Milan (mln)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
197
