Mercury 2009 Sable User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
14 20A** Power point (2nd row)
15 — Not used
16 20A** Power point (console)
17 10A** Alternator
18 — Not used
19 — Not used
20 40A* Rear defroster
21 30A* Power seat motors (passenger)
22 20A* Heated seat module
23 10A** PCM Keep alive power, Canister
vent
24 10A** A/C clutch relay
25 — Not used
26 20A** Backup relay
27 15A** Fuel relay (Fuel pump driver
module, Fuel pump)
28 — Not used
29 — Not used
30 — Not used
31 — Not used
32 30A* Driver seat motors, Memory
module
33 20A* Ignition switch (to SJB)
34 — Not used
35 40A* Front A/C blower motor
36 1A Diode One-touch start
37 1A Diode Fuel pump
38 10A** IVD, Yaw rate sensor
39 10A** Fuel diode, PCM
40 — Not used
41 G8VA relay A/C clutch
2009 Sable (mgo)
Owners Guide, 1st Printing
USA (fus)
Roadside Emergencies
263
