1B-38 - MAINTENANCE 90-823225--1 1096
g. On All Models With a Walter V-Drive Trans-
mission, disconnect water inlet hose from
the fitting on transmission.
75192
a
a
Walter V-Drive Transmission
a - Drain Plug (2) One Hidden In This View
h. Remove seawater pump inlet hose as shown.
72532
b
a
a - Seawater Pickup Pump
b - Hose
i. Crank engine over SLIGHTLY, with starter
motor, to purge any water trapped in seawa-
ter pickup pump. DO NOT ALLOW ENGINE
TO START.
!
CAUTION
If boat is in the water or is to remain in the water,
seacock (if so equipped) must remain closed un-
til engine is to be restarted, to prevent water from
flowing back into cooling system. If boat is not
fitted with a seacock, seawater inlet hose must
remain disconnected and plugged, to prevent
water from flowing into cooling system and/or
boat. As a precautionary measure, attach a tag to
the ignition switch or steering wheel with the
warning that the seacock must be opened or the
seawater inlet hose reconnected prior to starting
the engine.
j. After seawater section of cooling system has
been drained completely, coat threads of
drain plugs with Quicksilver Perfect Seal and
reinstall. Tighten drain plugs securely. Re-
connect hoses and tighten all hose clamps
securely. If NOT equipped with seacock:
seawater inlet hose must remain discon-
nected and plugged until engine is to be re-
started.
