Mercury 4000 MPC GEN 2 User Manual

4000 MPC GEN 2 PISTOL GRIP REMOTE CONTROL INSTALLATION/OPERATION INSTRUCTIONS
90-899782001 APRIL 2008 Page 15 / 23
6. Align the tabs on the bezel cover with the slots on the bezel. Snap the bezel cover in
place.
24971
a
b
c
a - Bezel
b - Tabs (4)
c - Bezel cover
7. Apply Loctite 271 Threadlocker on the threads of the control handle retaining bolt.
NOTE: A new control handle retaining bolt has threadlocking compound on the threads.
A control handle retaining bolt that was installed and removed must have Loctite 271
Threadlocker applied to the threads.
!
WARNING
Improper installation can result in sudden, unexpected loss of throttle and shift control,
resulting in serious injury or death. Install all control components properly.
8. Install the control handle assembly onto the remote control module. Ensure the control
handle is in neutral and in the desired position.
