Lubrication Points
1.
Lubricate the following with 2‑4‑C with PTFE or Extreme Grease.
Tube Ref
No.
Description Where Used Part No.
Extreme Grease
Swivel bracket, transom clamp screws,
tilt tube, throttle and shift cables,
steering cable grease fitting
8M0071842
95
2-4-C with PTFE
Swivel bracket, transom clamp screws,
tilt tube, throttle and shift cables,
steering cable grease fitting
92-802859A 1
• Swivel bracket ‑ Lubricate fitting.
•
Transom clamp screws ‑ Lubricate threads.
• Tilt tube ‑ Lubricate fittings.
a - Tilt tube grease fitting
b - Swivel bracket grease fitting
c - Transom clamp screws
MAINTENANCE
eng 71
