GENERAL SYSTEM DIAGNOSTICS SERVICE MANUAL NUMBER 23
Page 5E-96 90-861326--1 MARCH 1999
Discrete Input Circuit Check - Non-Scan 454 / 502 Mag MPI and 8.2L MP Only
(5 of 5)
TESTING FOR OPEN CIRCUITS
STEP
ACTION VALUE YES NO
PROCEED TO
1
1. Disconnect PUR wire from oil pressure
switch.
2. Disconnect TAN/WHT wire from gear
lube monitor.
3. Disconnect BLU/TAN wire from transmis-
sion temperature switch (if equipped).
4. Key “ON”, engine “OFF”.
5. One at a time, touch each wire to ground
(–) that was disconnected.
Does audio warning buzzer sound when
grounding BLU/TAN wire from oil pressure
switch?
Step 3 Step 2
Does audio warning buzzer sound when
grounding BLU/TAN wire from gear lube
switch?
Step 3 Step 2
Does audio warning buzzer sound when
grounding BLU/TAN wire from transmission
switch?
Step 3 Step 2
2
1. Key “OFF”.
2. Disconnect ECM J1 connector.
3. Check for continuity between all wires
disconnected in “Step 1” and terminal J1-6.
Is there continuity on BLU/TAN wire from
oil pressure switch?
Step 3 Step 4
Is there continuity on BLU/TAN wire from
gear lube switch?
Step 3 Step 4
Is there continuity on BLU/TAN wire from
transmission switch?
Step 3 Step 4
3 Circuit(s) is not open. – –
4 Repair open circuit. – –
NOTE: The ECM should only be replaced after all switches and circuits have been tested
and found to be functioning properly.
