Item Capacity Ford part name
Ford part number / Ford
specification
Power transfer unit
(PTU) fluid (AWD)
5
12 ounces
(0.35L)
Motorcraft SAE
75W-140 Synthetic
Rear Axle Lubricant
XY-75W140-QL /
WSL-M2C192-A
Windshield washer
fluid
4.75 quarts
(4.5L)
Motorcraft Premium
Windshield Washer
Concentrate
ZC-32-A /
WSB-M8B16-A2
Fuel tank (FWD)
17.5 gallons
(66.2L)
——
Fuel tank (AWD)
16.5 gallons
(62.4L)
——
1
Add the coolant type originally equipped in your vehicle.
2
Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the
requirements of Ford specification WSS-M2C930-A and the API Certification mark.
3
Service refill capacity is determined by filling the transmission within 3/8 inch (10mm) of the
bottom of the filler hole with the vehicle on a level surface.
4
Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and
if equipped with an in-tank cooler. The amount of transmission fluid and fluid level should be set
by the indication on the dipstick’s normal operating range.
5
The Power Transfer Unit is lubricated for life with synthetic lube. Lubricant levels are not to be
checked or changed unless a leak is suspected or repair required. Replace Power Transfer Unit
lubricant with specified synthetic lubricant anytime the unit is submerged in water.
See your authorized dealer for fluid level checking or filling of the Power Transfer Unit.
2009 Milan (mln)
Owners Guide
USA (fus)
Maintenance and Specifications
305
