Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse Panel
Description
11 — Not used (spare)
12 5A Foglamp switch, 4x4 module
13 5A Overdrive cancel switch, Flex fuel sender
14 5A PATS module
15 5A Rear wiper module, Cluster, TPMS
16 5A Power mirror, Manual climate control,
TPMS
17 15A Delayed acc. coil, Battery saver, Interior
lamps (front and rear), Glove
compartment lamp
18 10A Left horn
19 10A RCM, PAD indicator
20 5A PATS, Driver seat switch, Memory switch,
Driver seat module, BSM, Sunload sensor
21 5A Instrument cluster, Compass, Flasher coil
22 10A ABS, IVD Controller
23 15A Brake pedal position switch, Driver brake
applied relay, Redundant cruise deactivate
switch
24 15A Cigar lighter, OBD II
25 5A Mode-Temperature actuator for auxiliary
climate control, Trailer tow battery charge
coil
26 7.5A Park aid, Brake shift interlock, Approach
lamp relay coil, IVD switch
27 7.5A Electrochromatic mirror, Digital
transmission range sensor - backup lamps
28 5A Radio (Start)/DVD (Start)
29 10A Digital transmission range sensor, PWR
feed to fuse #28 (Start feed)
30 5A Daytime Running Lamps (DRL), Remote
solenoid, DEATC climate controller
Roadside emergencies
209
