600.101/102UK User Manual
Series Multimeters Function Table
MODEL DCV ACV DCA OHM hFE
MTB01
√ √ √ √ √ √ √ √
MTB02
√ √ √ √ √ √
Technical Specifications
Accuracies are guaranteed for 1 year, 23℃±5℃, less
than 80%RH
DC VOLTAGE
RANGE RESOLUTION ACCURACY
200mV 100uV ±(0.5% of rdg + 3D)
2000mV 1mV
20V 10mV
200V 100mV
500V 1V ±(1.0% of rdg + 5D)
±(0.8% of rdg + 5D)
OVERLOAD PROTECTION: 220V rms AC for 200mV range
and 500V DC or 500Vrms for all ranges.
AC VOLTAGE
RANGE RESOLUTION ACCURACY
200V 100mV
500V 1V
±(2.0% of rdg +10D)
RESPONSE: Average responding, calibrated in rms of a
sine wave.
FREQUENCY RANGE: 45Hz ~ 450Hz
OVERLOAD PROTECTION: 500V DC or 500V rms for all
ranges.
