5.
Remove
the
rubber
plug
from
the
lower
access
hole
in
the
upper
portion
of
the
liftgate.
6.
Remove
four
nuts
from
the
lamp
assembly
.
7.
Carefully
lift
the
lamp
assembly
away
from
the
liftgate.
8.
Remove
the
bulb
socket
by
rotating
it
counterclockwise
and
pulling
it
out
from
the
lamp
assembly
.
9.
Carefully
pull
the
bulb
straight
out
of
the
socket
and
push
in
the
new
bulb.
10.
T
o
complete
installation,
follow
the
removal
procedure
in
reverse
order
.
Maintenance
and
care
198
