Merrytek MC601V - Detection Patterns; Wall Mounting Detection Pattern; Ceiling Mounting Detection Pattern

Wiring scheme
If with sufficient ambient
light, the lamp turns off
at once,even with motion
trigger.
If with insufficient ambient light, the lamp dims to stand-by dimming level (Set in the motion
sensor) when no motion detected ofter hold time, and then switches off after stand-by period.
3
6
6
12
Detection Pattern
Ceiling mounting pattern (Unit: m)
Suggested installation height: 2.5-10m
Wall mounting pattern (Unit: m)
Suggested installation height: 1-1.8m
10 %
25 %
50 %
75 %
10 0%
0
2
4
8
6
2
4
6
8
10 12 14
10
12
14
10
12
14
16
16
16
18
18
18
10 %
50 %
75 %
10 0%
