APPLICATION SUPPORT AND OVER-THE-AIR QoS
SIP and H.323 support
Dynamic out-of-the-box support for SIP and H.323 applications
and codecs
QoS
Configurable QoS rules for SIP, H.323, Ascom, Avaya, Microso,
Polycom, Siemens, and Shoretel
User-configurable static and dynamic QoS rules per application
(user-defined) and per user (stations, users, and port numbers)
Call Admissions Control and Call Load Balancing
WMM Support
WMM Rate Adaptation, optimized based on real-time network
conditions
SECURITY
Authentication
Combination of captive portal, 802.1x and open authentication
Advanced security using WPA2
802.1X with EAP-Transport Layer Security
(EAP-TLS), Tunneled TLS (EAP-TTLS), Protected EAP (PEAP)
MSCHAPv2, Smartcard/Certificate, Lightweight EAP (LEAP),
EAP-FAST and EAP-MD5, with mutual authentication and dynamic,
per user, per session unicast and broadcast keys
Secure HTTPS w/customizable Captive Portal utilizing RADIUS
Encryption Support
Static and dynamic 40-bit and 128-bit WEP keys, TKIP with MIC, AES,
SSL, TLS
Security Policy
Radius Assisted, Per User and Per ESSID Access control via MAC
Filtering; Multiple ESSID/BSSID each with flexibility of separate and
shared Security Policy
Rogue Detection and Suppression
All radios capable of scanning 802.11n, 802.11a and 802.11b/g
for rogue devices
Security Firewall
10,000 simultaneous sessions
System configured or per user radius configured firewall policy
MOBILITY
Zero-loss Handos
Infrastructure-controlled zero-loss hando mechanism for standard
Wi-Fi
®
clients
Virtual Cell Load Balancing
Virtual Cell provides load balancing coordination for improved
performance and WLAN resiliency upon AP failure
CENTRALIZED MANAGEMENT
Zero-Configuration
Automatically selects power and channel settings
Automatically discovers controllers and download configuration settings
Zero touch, plug and play deployments
System Management
Centralized and remote management and soware upgrades via
System Director web-based GUI, SNMP, Command-Line Interface
(CLI) via serial port, SSH, Telnet, centrally managed via E(z)RF
Management Suite
Centralized Security Policy for WLAN, Multiple ESSIDs and VLANs
with their own administrative/security policies
Intelligent RF Management
Coordination of access points with load-balancing for predictable
performance; Centralized auto-discovery, auto-channel configuration,
and auto-power selection for APs; Co-channel interference management
WIRED/WIRELESS SUPPORT
Wireless Compliance
IEEE 802.11 a/b/g/n, IEEE 802.11i support (AES, WEP, WPA, WPA2),
IEEE 802.11e, WMM
Automatic Discovery & Configuration
All Meru Access Points
Wired/Switching
IEEE 802.1Q VLAN tagging, GRE Tunneling and IEEE 802.1D
Spanning Tree Protocol
PHYSICAL SPECIFICATIONS
Dimensions
16.97” width x 1.74” height x 16.49“ depth
(43.1 cm width x 4.45 cm height x 41.88 cm depth)
Weight
20 lbs 15 oz
Power
Single 270W PSU
Environmental
Operating Temperature: 0° to 40° C (32° F to 104° F)
Operating Humidity: 95% at 40° C (104° F)
Storage Temperature: -40° to 85° C (-40° F to 185° F)
Storage Humidity: 95% at 40° C (104° F)
Interfaces
4 10/100/1000 Base-T Ethernet
RJ45 Console Port
2 x USB Port
Power On/O Switch
Ethernet Port Status Lights (LED) for Link/Activity/Speed
Access Point and Client Support
200 APs and up to 2,000 Wi-Fi clients
Mounting
1U Rack Mount
Standard Warranty
1 year
Certifications
Wi-Fi Certified a/b/g/n
RoHS Compliant
Safety Standards
UL 60950-1
IEC 60950-1
EMC
FCC Part 15/ICES-003 Class A
VCCI Class A - Japan
EN 55022 Class A - Europe
EN 55024 – Europe
EN60601-1 – Europe
EN60601-1-2 - Europe
KCC - Korea
MC3200
TECHNICAL SPECIFICATIONS
Corporate Headquarters
894 Ross Drive, Sunnyvale, CA 94089
T +1 (408) 215-5300
F +1 (408) 215-5301
E info@merunetworks.com
For more information about Meru MC3200 visit www.merunetworks.com or email your questions to: info@merunetworks.com
Meru Networks | Copyright © 2011 Meru Networks, Inc. All rights reserved worldwide. Meru Networks is a registered trademark of Meru Networks, Inc. in
the US and worldwide. All other trademarks, trade names or service marks mentioned in this document are the property of their respective owners. 04015
