ALL VEHICLES
2-SHAFT HEAD UNITS: Attach the Faceplate to the Radio Housing. Slide the
aftermarket head unit into the kit and secure with shaft nuts.
(See Fig. A)
DIN HEAD UNITS: Cut and remove the shaft supports from the Faceplate. Snap the
converted Faceplate onto the front of the Radio Housing. Slide the DIN cage into
the kit and secure by bending the metal locking tabs down. Slide the aftermarket
head unit into the cage until secure. (See Fig. B)
99-4503
KIT ASSEMBLY/FINAL ASSEMBLY
