METREL EurotestXE User Manual

MI 3102(H) BT EurotestXE Technical specifications
101
10.12 First fault leakage current – ISFL (MI 3102 BT only)
Measuring range (mA)
Resolution (mA)
Accuracy
0.0  19.9
0.1
±(5 % of reading + 3 digits)
Measuring resistance .................................. approx. 390 
Nominal voltage ranges .............................. 93 V  U
L1-L2
 134 V
185 V  U
L1-L2
 266 V
10.13 Calibrated resistance for IMD testing (MI 3102 BT only)
Threshold indicative insulation resistance
Measuring range (kΩ)
Resolution (kΩ)
Notes
5  640
5
Indicative values
Up to 128 steps
Nominal voltage ranges .............................. 93 V  U
L1-L2
 134 V
185 V  U
L1-L2
 266 V
First fault leakage current at threshold insulation resistance
Measuring range (mA)
Resolution (mA)
Note
0.0  19.9
0.1
calculated value*
)
*
)
See chapter 5.14 Testing of insulation monitoring devices – IMD (MI 3102 BT only) for more
information about calculation of first fault leakage current at threshold insulation resistance.
