METREL EurotestXE User Manual

MI 3102(H) BT EurotestXE Instrument operation
30
Clamp settings
A1391, 40A
Test mode:
Function
Parameters / limit value
Sub-function
EARTH RE, 2 clamps
No limit
EARTH 
2.0 m
R ISO
No limit
Nominal test voltage: 500 V
Low Ohm Resistance
R LOW
No limit
CONTINUITY
No limit, sound OFF
Rpe
No limit
Rpe(rcd)
No limit
Z - LINE
Fuse type: none selected
VOLTAGE DROP
ΔU: 4.0 %
Z
REF
: 0.00 Ω
Z - LOOP
Fuse type: none selected
Zs rcd
Fuse type: none selected
RCD
RCD t
Nominal differential current: I
N
=30 mA
RCD type: AC, non-delayed
Test current starting polarity: (0)
Limit contact voltage: 50 V
Current multiplier: 1
AUTO SEQUENCES:
AUTO TT
FUSE: None selected
Z
REF
: ---
ΔU: 4.0 %
RCD: 30 mA, AC, non-delayed, (0)
Uc: 50 V
AUTO TN (rcd)
FUSE: None selected
Z
REF
: ---
ΔU: 4.0 %
Rpe: No limit
AUTO TN
FUSE: None selected
Z
REF
: ---
ΔU: 4.0 %
Rpe: No limit
AUTO IT*
FUSE: None selected
Z
REF
: ---
ΔU: 4.0 %
ISFL: 3.0 mA
IMD: AUTO R, 35 kΩ, 2 s
OTHERS:
HARMONICS
U
h:1
SENSOR
No limit
ISFL*
No limit
IMD*
AUTO R, 30 kΩ, 2 s
DIAG. TEST**
Nominal test voltage: 500 V
* MI 3102 BT only
** MI 3102H BT only
