METREL EurotestXE User Manual

MI 3102(H) BT EurotestXE Measurements
61
PE terminal test procedure
 Connect test cable to the instrument.
 Connect test leads to the item to be tested ( see Figure 5.43 and Figure 5.44).
 Touch PE test probe (the TEST key) for at least one second.
 If PE terminal is connected to phase voltage the warning message is displayed,
instrument buzzer is activated, and further measurements are disabled in Zloop and
RCD functions.
Warning:
 If dangerous voltage is detected on the tested PE terminal, immediately stop all
measurements, find and remove the fault!
Notes:
 PE test terminal is active in the INSTALLATION operating mode (except in the
VOLTAGE, Low ohm, Earth and Insulation functions).
 PE test terminal does not operate in case the operator’s body is completely insulated
from floor or walls!
 For operation of PE test terminal on commanders refer to chapter Appendix D –
Commanders (A 1314, A 1401).
