METREL EurotestXE User Manual

MI 3102(H) BT EurotestXE Technical specifications
92
10.4.2 Contact voltage RCD Uc
Measuring range according to EN 61557 is 20.0 V  31.0V for limit contact voltage 25V
Measuring range according to EN 61557 is 20.0 V  62.0V for limit contact voltage 50V
Measuring range (V)
Resolution (V)
Accuracy
0.0  19.9
0.1
(-0 % / +15 %) of reading ± 10 digits
20.0  99.9
0.1
(-0 % / +15 %) of reading
The accuracy is valid if mains voltage is stabile during the measurement and PE terminal is free
of interfering voltages.
Test current ........................................... max. 0.5I
N
Limit contact voltage .............................. 25 V, 50 V
Specified accuracy is valid for complete operating range.
10.4.3 Trip-out time
Complete measurement range corresponds to EN 61557 requirements.
Maximum measuring times set according to selected reference for RCD testing.
Measuring range (ms)
Resolution (ms)
Accuracy
0.0  40.0
0.1
1 ms
0.0  max. time *
0.1
3 ms
* For max. time see normative references in chapter4.4.5 RCD testing. This specification
applies to max. time >40 ms.
Test current ........................................... ½I
N
, I
N
, 2I
N
, 5I
N
5I
N
is not available for I
N
=1000 mA (RCD type AC) or I
N
 300 mA (RCD types A, F).
2I
N
is not available for I
N
=1000 mA (RCD types A, F).
Specified accuracy is valid for complete operating range.
10.4.4 Trip-out current
Trip-out current
Complete measurement range corresponds to EN 61557 requirements.
Measuring range I

Resolution I

Accuracy
0.2I
N
 1.1I
N
(AC, EV and MI a.c. type)
0.05I
N
0.1I
N
0.2I
N
 1.5I
N
(A type, I
N
≥30 mA)
0.05I
N
0.1I
N
0.2I
N
 2.2I
N
(A type, I
N
<30 mA)
0.05I
N
0.1I
N
0.2I
N
 2.2I
N
(B, EV and MI d.c. type)
0.05I
N
0.1I
N
Trip-out time
Measuring range (ms)
Resolution (ms)
Accuracy
0  300
1
3 ms
Contact voltage
Measuring range (V)
Resolution (V)
Accuracy
0.0  19.9
0.1
(-0 % / +15 %) of reading  10 digits
20.0  99.9
0.1
(-0 % / +15 %) of reading
The accuracy is valid if mains voltage is stabile during the measurement and PE terminal is free
of interfering voltages.
Trip-out measurement is not available for I
N
=1000 mA (RCD types B, B+).
Specified accuracy is valid for complete operating range.
