MI 3122 Smartec Z Line-Loop / RCD Function selection
18
4 Instrument operation
4.1 Function selection
For selecting test function the FUNCTION SELECTOR shall be used.
Keys:
FUNCTION
SELECTOR
Select test / measurement function:
<VOLTAGE TRMS> Voltage and frequency and phase sequence.
<Z-LINE> Line impedance.
<Z-LOOP> Fault loop impedance.
<RCD> RCD testing.
<SETTINGS> General settings.
UP/DOWN
Selects sub-function in selected measurement function.
TAB
Selects the test parameter to be set or modified.
TEST
Runs selected test / measurement function.
MEM
Stores measured results / recalls stored results.
Keys in test parameter field:
UP/DOWN
Changes the selected parameter.
TAB
Selects the next measuring parameter.
FUNCTION SELECTOR
Toggles between the main functions.
MEM
Stores measured results / recalls stored results.
General rule regarding enabling parameters for evaluation of measurement / test result:
Parameter
OFF
No limit values.
ON
Value(s) – results will be marked as PASS or FAIL in
accordance with selected limit.
See Chapter 5 for more information about the operation of the instrument test functions.
