4.2 Settings
Different instrument options can be set in the SETTINGS
menu.
Options are:
Selection of language,
Setting the instrument to initial values,
Recalling and clearing stored results,
Setting the date and time,
Selection of reference standard for
RCD test,
Entering Isc factor,
Support of commanders.
UK version
Figure 4.1: Options in Settings menu
Keys:
UP / DOWN
Selects appropriate option.
TEST
Enters selected option.
Function selectors
Exits back to main function menu.
4.2.1 Language
The instrument supports different languages.
Figure 4.2: Language selection
Keys:
UP / DOWN
Selects language.
TEST
Confirms selected language and exits to settings menu.
Function selectors
Exits back to main function menu.
