Made by ALL Engineering
Technical specs :
Working principle: Non oversampling digital pre amplifier.
Dual mono, four dacs per channel in differential mode.
Power supply: 75 VA devided over three single toroidial transformers
Power consumption: Standby < 1.5 Watts
Full operation 25 Watts
Power requirement: 110/115V AC or 220/230 V AC 60/50Hz
Inputs: 1x optical Toslink, 2x coaxial like 1x BNC , 1x RCA.
AES/EBU and USB module.
Outputs: 2x RCA gold plated Neutrik © connectors . 2x XLR 3
balanced outputs.
Output voltage: RCA : 2 Volts RMS max output. -10dB setting 700mV RMS
XLR: 4 Volts RMS max output -10dB setting 1.4 Volts RMS
Frequency response: 1Hz -0.8dB, 20 kHz -1.2 dB 44.1kHz sampling.
1Hz -0.8dB, 65 kHz -3dB 192-384 kHz sampling.
Distortion: 0,01 % THD
Noise: -145 dB related to 2 Volt RMS
Output impedance: RCA 100 Ohms , XLR 200 Ohms
Sampling frequency: Optical : 44.1 - 96 kHz sampling ,16 or 24 bits.
Coaxial: 44.1 - 192 kHz sampling, 16 or 24 bits.
USB: 44.1- 384 kHz sampling , 16 or 24 bits
Dimensions hxwxd: 85 x 440 x 320 mm.
Weight: 11kg.
Subject to change without notice.
