TABLE 3 - PARTS LIST FOR (FIGURE 24)
Part # Qty Part Description Material
1 1 Octi-Cam (Stop Arrangement) Stainless Steel / Carbon Steel (1)
2 2 Stop Cap Screw Stainless Steel
3 2 Washer (Stop Cap Screw) Stainless Steel
4 2 Nut (Stop Cap Screw) Stainless Steel
5 x 2 Bearing (Piston Back) High Grade Polymer
6 x 1 Bearing (Pinion Top) High Grade Polymer
7 x 1 Bearing (Pinion Bottom) High Grade Polymer
8 x 2 Thrust Bearing (Pinion) High Grade Polymer
9 xy 2 Plug (Transfer Port) Silicone
10 1 Thrust Washer (Pinion) Stainless Steel
11 xy 2 O-ring (Stop Cap Screw Seal) Special NBR
12 2 Piston Guide High Grade Polymer
13 8/12/16/ (2) Cap Screw (End Cap) Stainless Steel
14 xy 2 O-ring (End Cap) Special NBR
15 x 2 Bearing (Piston Head) High Grade Polymer
16 xy 2 O-ring (Piston) Special NBR
17 min. 5/ max.12 Spring (Cartridge) Alloy Steel - Epoxy Coated
18 1 Spring Clip (Pinion) Spring Steel - ENP
19.0 1 Graduated Ring High Grade Polymer
19.1 1 Position Indicator High Grade Polymer
19.5 1 Top Adaptor Extruded Aluminum - Anodized
19.6 2 Hex Socket Set Screw Stainless Steel
20 xy 1 O-ring (Pinion Bottom) Special NBR
21 xy 1 O-ring (Pinion Top) Special NBR
30 2 End Cap Cast Aluminum - Anodized - Coated
39 1 Cap Screw (Indicator) High Grade Polymer
40 2 Piston Cast Aluminum - Anodized - Coated
41 1 Actuator Identication Label Polyester Aluminum
50 1 Body Extruded Aluminum - Anodized - Coated
60 1 Drive Shaft Carbon Steel Plated
65 1 Plastic Insert High Grade Polymer
Spare parts for maintenance
x - Included in Complete Kit
y - Included in O-ring Kit
Notes: (1) AISI304 for models VPVL-051 through 300; Carbon Steel for models VPVL-350 through 800
(2) Qty 8 pieces for models VPVL-051 through 600; Qty 12 pieces for model VPVL-700 and Qty 16 pieces for model VPVL-800.
