4. 1602 LCD instructions in time sequence that
1602 LCD module internal controller of article 11 control instruction, as the chart shows:
Numb
ers
instructions RS R/W D7 D6 D5 D4 D3 D2 D1 D0
1 Clear display 0 0 0 0 0 0 0 0 0 1
2 Cursor to return to 0 0 0 0 0 0 0 0 1 *
3 Buy input mode 0 0 0 0 0 0 0 1 I/D S
4
Display the on/off
control
0 0 0 0 0 0 1 D C B
5
The cursor or character
shift
0 0 0 0 0 1 S/C R/L * *
6 Buy function 0 0 0 0 1 DL N F * *
7
Buy character CunZhuQi
address happens
0 0 0 1 Characters CunZhuQi address happens
8 Buy data CunZhuQi 0 0 1 Display the data CunZhuQi address
9
Read busy symbols or
address
0 1 BF Counter address
10
Write count to CFRAM or
DDRAM
1 0 To write data content
11
From CFRAM or DDRAM
readings
1 1 Read data content
