HERBI 4 STANDARD COMPONENTS - PARTS LIST
ITEM PART No. DESCRIPTION QTY.
1 4993 TUBE 6MM ID X 9MM OD - PVC 1.2 m
2 7831 CABLE TIE 2
3 5446 EXTENSION TUBE 1
4 5376 BATTERY CASE END CAP 1
5 5399 SCREW, S/T NO.6X3/8" PZ PAN HD. B 7
6 4907 WING NUT 1
7 HB4_101 HERBI 4 ATOMISER HEAD ASSEMBLY 1
8 5029 SCREW M5 1
9 4368 WIRE, 1.0 MM, RED - PER METRE 1.25 m
10 4134 WIRE, 1.0 MM, BLACK (PER METRE) 1.3 m
11 5575 RING TERMINAL 2
12 4447 SPRING HOLDING PIN 1
13 4646 SCREW, S/T NO.6X3/8" PZ. FL.HD. AB 1
14 5363 BATTERY SPRING 1
15 5375 CENTRE CONNECTOR 1
16 5447 BATTERY CASE 1
17 5956 SCREW, M5X12 PT 1
18 5780 VALVE CLAMP 1
19 7465 SCREW SWITCH SLEEVE 1
20 7495 CONNECTOR, SCREW SWITCH 1
21 7464 SCREW SWITCH PLUG 1
22 8621 LABEL BATTERY 1
23 8673 LABEL HERBI 4
