MicroTouch OF-215P-B1 User Manual

32
Supported Timings
Mode
Resolution
H-Freq. (KHz)
Bandwidth (MHz)
Polarity
H
V
1
720 x 400 @ 70Hz
31.47
28.322
-
+
2
640 x 480 @ 60Hz
31.47
25.175
-
-
3
640 x 480 @ 66Hz
35
32.24
-
-
4
640 x 480 @ 72Hz
37.86
31.5
-
-
5
640 x 480 @ 75Hz
37.5
31.5
-
-
6
800 x 600 @ 56Hz
35.16
36
+
+
7
800 x 600 @ 60Hz
37.88
40
+
+
8
800 x 600 @ 75Hz
46.88
49.5
+
+
9
800 x 600 @ 72Hz
48.08
50
+
+
10
832 x 624 @ 75Hz
49.72
57.283
-
-
11
1024 x 768 @ 60Hz
48.36
65
-
-
12
1024 x 768 @ 70Hz
56.48
75
-
-
13
1024 x 768 @ 75Hz
60.02
78.75
+
+
14
1280 x 1024 @ 60Hz
64
108
+
+
15
1280 x 1024 @ 75Hz
80
135
+
+
16
1152 x 864 @ 75Hz
67.5
108
+
+
17
1280 x 960 @ 60Hz
60
108
+
+
18
1440 x 900 @ 60Hz
56
106.5
-
+
19
1440 x 900 @ 75Hz
70.6
136.75
-
+
20
1680 x 1050 @ 60Hz
65.2
146
-
+
21
1680 x 1050 @ 75Hz
82.3
187
-
+
22
1280 x 768 @ 60Hz
47.776
79.5
-
+
23
1920 x 1080 @ 60Hz
67.5
148.5
+
+

MicroTouch OF-215P-B1 Specifications

General

Brand	MicroTouch
Model	OF-215P-B1
Category	Monitor
Language	English
