Midea D30-15FA3

4
2.3 Internal Wire Diagram
WIRING DIAGRAM
(Note:All dimensions are in mm)
D50-15FA3
450
600
100
200
D80-15FA3
450
809
100
200
D100-15FA3
450
974
100
200
A
B
C
D
D30-15FA3
340
594
100
200
Heating Element
Heating Indicator Light
Thermal
Cut Out
Thermostat
Brown
Blue
Yellow/Green
1
2
