Midea FZ10-8HC User Manual

2
PART FIGURE
Note: All the pictures in this manual are for explanation purpose only. Any discrepancy between
the real object and the illustration in the drawing shall be subject to the real subject.
1. Body
2. Front base
3. Rear base
4. Plastic nut
5. Power cord
1. Take the chassis, fan body from the packing box and combine two parts of the
chassis with two screws.(See Fig.1)
2. Pass the power cord through the flute, then Insert the fan body in the chassis.
(See Fig.3)
3. Fix the fan body on the chassis with plastic nut. (See Fig.2)
ASSEMBLY INSTRUCTIONS
The outlet trough
Fig.1
Fig.2 Fig.3

Midea FZ10-8HC Specifications

General

Brand	Midea
Model	FZ10-8HC
Category	Fan
Language	English
