Midea MCD-24HRFN1-M(C)

279
 MOX230-09HFN1-MW5W, MOX230-12HFN1-MV5W, MOX330-09HFN1-MY5W,
MOX330-12HFN1-MW5W
No.
Part name
Procedures
Remarks
1
Panel plate
How to remove the panel
plate.
1)Stop operation of the
air conditioner and turn
“OFF” the power breaker.
2) Remove the big handle
first(3 screws)
3) Remove the top
cover (4 screws)
4)Remove the screws of
front panel(9 screws)
