127
7) Disconnect the fan motor
connectors FAN1(3p,white)
and FAN2(3p,white) from DC
motor driver board.
8) Remove the fan motor after
unfastening fixing screws.
2 Panel plate How to remove the panel
plate.
4) Remove big handle.(2
screws) and water
collector(2 screws)
5) Remove 2 screws of
terminal board and 15
screws of right-rear panel,
and remove the right-rear
panel.
3 Electrical
parts
How to remove the electrical
parts.
1) Perform work of item 1
step 5~6 and item 2.
