2. Remove the upper left hinge cover decorative cover, upper right hinge cover and upper right hinge, and
disconnect the right signal line (signal line terminal 1, 2) at the top of the box body.
3. Remove the refrigerated door body (be careful not to lose small parts such as the shaft sleeve and stop on the
door);
Remove the middle hinge and remove the decorative cover of hinge hole on the other side.
4. Remove the freezing door body (be careful not to lose small parts such as the shaft sleeve and stop on the
door);
Remove the hinge and adjust the angle. Remove and install the lower hinge shaft to the other side of the hinge, and
install the modified lower hinge to the other side of the box.
upper hinge cove
upper hinge
decorative
cove
decorative cover
middle hinge
To Next Page
