7 Installation of Front Grill
7.1 From top to bottom align the clips of the front grill with the uppermost mesh of
the rear grill.
After the alignment is correct, look from back to front according to the diagram.
7.2 Press the grills in order with both hands. A sound of "click" will be heard when
installed right.
7.3 Self-clipped installation.
Pa!
A straightly placed Logo
indicates the grills have
been correctly aligned.
