MCAC-TSM-2008-02 Outdoor units
Outdoor units 25
MGC-F10W/SN1
Ta Tw 5 6 7 8 9 10
Pf 10.9 11.2 11.5 11.8 12.1 12.4
Pa 2.6 2.6 2.7 2.7 2.7 2.8
Pat 3.1 3.1 3.2 3.2 3.2 3.3
Qev 1.9 1.9 2.0 2.0 2.1 2.2
25
△Pev
31.5 31.7 33.0 33.5 36.0 38.0
Pf 10.4 10.8 11.1 11.5 11.8 12.1
Pa 2.9 2.9 3.0 3.1 3.1 3.1
Pat 3.4 3.4 3.5 3.6 3.6 3.6
Qev 1.8 1.8 1.9 2.0 2.0 2.0
30
△Pev
29.8 30.4 31.8 33.2 33.6 33.9
Pf 9.9 10.2 10.5 10.7 11.0 11.3
Pa 3.3 3.3 3.4 3.4 3.5 3.5
Pat 3.8 3.8 3.9 3.9 4.0 4.0
Qev 1.7 1.7 1.8 1.9 1.9 2.0
35
△Pev
27.0 27.5 30.0 32.0 32.4 34.0
Pf 9.4 9.7 10.0 10.3 10.6 11.0
Pa 3.6 3.6 3.7 3.7 3.8 3.8
Pat 4.1 4.1 4.2 4.2 4.3 4.3
Qev 1.6 1.6 1.7 1.7 1.8 1.8
40
△Pev
24.0 24.4 27.2 27.6 30.3 30.5
Pf 9.0 9.3 9.5 9.8 10.0 10.3
Pa 3.8 3.8 3.9 3.9 4.0 4.0
Pat 4.3 4.3 4.4 4.4 4.5 4.5
Qev 1.5 1.6 1.6 1.7 1.7 1.8
43
△Pev
21.0 23.8 24.4 27.0 27.5 31.0
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pf: cooling capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qev: evaporator water flow (m
3
/h)
ΔPev: evaporator pressure drop (kPa)
