MCAC-TSM-2008-02 Outdoor units
Outdoor units 43
No. Part Name Quantity No. Part Name Quantity
1 Rear net 1 17 Grille 1
2 Baffle ass'y 1 18 Axial flow fan 1
3 Rear net clap 1 19 Bearing base 1
4 Condenser ass'y 1 20 Heat-exchanger base ass'y 1
4.1 Condenser 1 21 Clamp 1
4.2 Condenser inlet pipe ass'y 1 22 Shieled pump ass'y 1
4.3 Condenser outlet pipe ass'y 1 23 Valve 1
5 E-part box ass'y 1 24 Expansion vessel 1
5.1 E-part box 1 25 Hydraulic meter 1
5.2 Capacitor 1 26 Compressor 1
5.3 Controller 1 27 Connecting pipe ass'y 1
5.4 AC contactor 1 28 Connecting pipe ass'y 1
5.5 Transformer 1 28.1 Water charge valve 1
5.6 Main control board ass'y 1 28.2 Safety valve 1
5.7 Urgency switch 1 29 Suction pipe ass'y 1
5.8 Filter board ass'y 1 29.1 Pressure controller 1
5.9 Compressor capacitor 1 30 Connecting pipe ass'y 1
6 Front right clapboard ass'y 1 30.1 Liquid accumulator can 1
7 Water inlet fixing board ass'y 1 31 4-way valve ass'y 1
8 Partition board ass'y 1 31.1 4-way valve 1
9 Top cover ass'y 1 31.2 Pressure controller 1
10 Motor bracket ass'y 1 31.3 Solenoid 1
11 Front panel 1 32 Inlet pipe ass'y 1
12 Base 1 33 Display cover ass'y 1
13 Left holder 1 34 Connecting pipe ass'y 1
14 Fixing board ass'y 1 34.1 Discharge valve 1
15 Motor 1 35 Valve electric heater 1
16 Heat-exchanger ass'y 1 36 Temp.sensor ass'y 3
16.1 Heat-exchanger ass'y 1 37 Discharge temp sensor 1
16.2 Heat-exchanger electric heater 1 38 Temp sensor ass'y 1
