MCAC-TSM-2008-02 Outdoor units
Outdoor units 45
No. Part name Quantity No. Part name Quantity
1 Rear support board II 1 22
Differential pressure valve below joint pipe
assembly
1
2 Condenser 1 23 water-up pipe assy subassembly 1
3 Condenser outlet subassembly 1 24 water-inlet pipe assy subassembly 1
4 Condenser inlet subassembly 1 25 Liquid storage pot connect pipe subassembly 1
5 Expansion vessel 1 26 Plate Heat-exchanger assy assembly 1
6 Accumulator cylinder 1 27 Right fixing board 1
7 Partition plate assembly 1 28 Left fixing board 1
8 Expansive jar clamp 1 29 Holder 1
9 Rear net clip 1 30 4-way valve subassembly 1
10 Water Pump 1 30.1 4-way valve 1
11
Expansion tank joint pipe
assembly
1 30.2 Control wire for 4-Ways valve 1
12
Electronic control box
subassembly
1 31 Discharge pipe subassembly 1
12.1 Motor capacitor 2 31.1 Pressure controller 1
12.2 E-part box 1 32 Suction pipe subassembly 1
12.3 Power filter plate subassembly 1 32.1 Pressure controller 1
12.4 Compressor capacitor 1 33 Compressor 1
12.5 Compressor capacitor 1 34 Transverse fixing board 1
12.6 Transformer 1 35 Show cover subassembly 1
12.7 Relay, compressor 1 36 Front panel 1
12.8 Contactor 1 37 Chassis Ass'y 1
12.9 wave flows out the curb 1 38 Net for air-out frame 2
13 Top cover assembly 1 39 Axial flow fan blade 2
14 Differential pressure valve 1 40 Motor mounting bracket subassembly 1
15 Front clapboard assembly 1 41 Outdoor fan Motor 2
16 Rear clapboard assembly 1 42 Supporting board 1
17 Urgency Switch 1 43 Rear net 1
18 Hydraulic surface 2 44 R410A 3kg
19 Handle 1 45 Temperature sensor subassembly 4
20 Adapter, drain pipe 1 46
Evaporator temp sensor Ⅱ subassembly
1
21 Handle 1
